Ruger PC Carbine Red Dot Mount – Fits Vortex Venom (Open Emitter), Viper, Burris FastFire & Docter Footprint Optics
Quick Check: Ruger PC Carbine, Henry and Marlin red dot mount.
Fits: Ruger PC Carbine, Henry lever actions, Marlin lever actions and additional rifles listed below.
Mounting Style: Receiver mount replacement.
Optic Footprint: Docter / FastFire / Viper / Venom compatible.
Mounting Hardware Included: Yes.
Installation & Overview
The EGW Ruger PC Carbine red dot mount adapter plate allows shooters to mount popular Docter footprint optics directly to compatible rifles and carbines without needing a Picatinny rail adapter. This mount is designed to provide a low-profile optic mounting solution for Vortex Venom, Vortex Viper, Burris FastFire and compatible red dot sights.
Precision machined from durable 7075 aluminum and finished in matte black hardcoat anodizing, this mount is built to withstand hard use while maintaining a clean and streamlined appearance on your firearm.
This mount is ideal for shooters looking to modernize lever guns, pistol caliber carbines and hunting rifles with a compact red dot optic while maintaining a lightweight and rugged setup.
Due to manufacturing tolerances between firearms, minor fitting may be required.
Learn more about optic footprints: RMR vs Docter vs RMSc Footprints Guide
Technical Specifications
- Material: 7075 Aluminum
- Finish: Matte Black Hardcoat
- Overall Length: 1.831"
- Overall Width: 1.062"
- Made In: USA
This Mount Fits
- Camp Carbine 9mm (does not fit early models, hole spacing differs)
- Camp Carbine .45
- Glenfield 30
- Henry Big Boy (H006)
- Henry 30-30 (H009)
- Henry 45-70 (H010)
- Henry Big Boy (H012)
- Henry Long Ranger (H014)
- Henry .410 (H018) – 20" barrel only
- Henry Side Gate Lever Action (H024)
- Henry Long Ranger
- Henry Homesteader (must use rear holes on receiver)
- Marlin 1895
- Marlin 1894
- Marlin 336
- Marlin 375
- Marlin 444
- Marlin Model 36
- Ruger PC Carbine
Compatible Red Dots
- Viridian RFX25
- Vortex Viper
- Vortex Venom (Open Emitter)
- Burris FastFire
- Burris FastFire 2
- Burris FastFire 3
- Burris FastFire 4
- Docter
- ADE RD3-001
- ADE RD3-002
- ADE RD3-009
- UTG Reflex Micro Dot
- Crimson Trace CTS-1200
- Crimson Trace CTS-1300
- Sightmark Mini Shot
- Cuda RX-795
Why Choose This EGW Mount?
- ✔ No permanent firearm modification required
- ✔ Low-profile optic mounting solution
- ✔ Precision machined from 7075 aluminum
- ✔ Compatible with many popular lever actions and carbines
- ✔ Designed for Docter footprint optics
- ✔ Made in the USA
Mounting Hardware Included
- (2) 6-32 x 5/16 Button Head Screws
- (2) 6-32 x 3/8 Flat Head Cap Screws
- (3) 8-40 x .313 Torx Screws (Red Bag)
- (3) 8-40 x .335 Torx Screws (Yellow Bag)
Installation Instructions
- Remove the factory rear sight or mounting screws
- Install the EGW Sight Mount
- Place the optic onto the EGW Sight Mount
- Apply blue Loctite to the mounting screws
- Torque mounting screws to 15 in/lbs
Fitment Notes
The Henry Homesteader must use the rear mounting holes on the receiver.
The Henry .410 mount fitment is limited to 20" barrel models only.
Due to manufacturing tolerances between firearms, minor fitting may be required.
WE RECOMMEND THIS PLATE BE INSTALLED BY A QUALIFIED AND COMPETENT GUNSMITH.
Modification of your firearm may nullify the manufacturer's warranty. This product should be installed and checked by a qualified gunsmith. No liability is expressed or implied for damage or injury which may result from improper installation or use of this product.
