Krebs 1911 Beavertail Cutting Fixture

$99.99
  • SKU: 70830
Out of stock
Current Stock:Only left:
Description

This Krebs beavertail milling fixture is designed to help a gunsmith properly cut and shape a 1911 pistol frame for the installation of a beavertail grip safety. It is now manufactured and sold by EGW. The fixture solidly holds the gun's frame in the correct position to be worked on, and clamps into any common milling machine's vise.

Technical Information

Notes:

  • Fixture fits into milling machine vise, holds 1911 frame
  • Pivot pin allows an evenly cut tang to accept any grip safety that uses a .250", .245" or .220" radius.
  • For use with 3/8" diameter end mill
  • Aluminum, 1/2" x 2" x 3 1/2"





Warning: This product may be alloyed with trace amounts of lead and other elements which are known to the State of California to cause reproductive harm and cancer. To prevent exposure, do not alter the product by welding, grinding, etc. For more information, go to www.P65Warnings.ca.gov.
